09140052616 HME-005-MS male 5 pins module, cage clamp heavy duty connector

Number of contacts:
5
Rated current:
16A
Part:
SO-HME-005-MS
Packaging Details:
Export carton
Delivery Time:
with 7 days
Payment Terms:
T/T
Supply Ability:
100000 pcs per month
Rated voltage conductor:
400V
Product Certification:
CE ROHS DMT
Order No.:
09140052616

09140052616 HME-005-MS male 5 pins module, cage clamp heavy duty connector

09140052616  HME-005-MS male 5 pins module, cage clamp heavy duty connector

Inserts
Number of contacts 5
Electrical dataacc. to EN 61 984
---Rated current 16A
---Rated voltage 400V
---Rated impulse voltage 6KV
-Pollution degree 3
Rated voltage acc. to UL 600V
Insulation resistance ≥10^10Ω
Material polycarbonate
Limiting temperatures -40℃...+125℃
Flammability acc. to UL 94 V0
Mechanical working life -mating cycles ≥500
Contacts
Material copper alloy
Surface hard-silver plated
Contact resistance 0.5mΩ
Screw terminal
---Wire gauge 0.14-2.5mm2
---AWG 26-14
