Air break switch ISAR-S 36kV 200A with rod assembly 9-11m
- Brand:
- SMICO
- Standard:
- IEC 62271-103,IEC 60265
- Electrical endurance:
- 100
- Mechnanical endurance:
- 1000
- Rated Voltage:
- 36KV
- Rated current:
- 200A
- Operating temperature:
- -25....40℃
- Storage temperature:
- -25....70℃
Description
ISAR-S load-break disconnector switches are designed for low-load breaking overhead MV
electrical lines.
Equipped with an air-break technology system combined with an isolating switch in series,
this device provides visible opening and great safety in operation.
ISAR-S switches are suitable for overhead distribution networks up to 36 kV, and especially
those requiring a high level of insulation:
In order to easy the logistics and the installation in difficult accessareas,ISAR-S load-break
switches are made up of three independent pre-assembled poles and single frame.
Specification
| Electrical endurance: | 100 O/C |
| Mechnanical endurance: | 1000 O/C |
| Operating temperature: | -25 ... 40 °C |
| Storage temperature: | -25 ... 70 °C |
| CHARACTERISTICS | ISAR-S 24KV | ISAR-S 36KV |
| Rated voltage(KV) | 24 | 36 |
| Rated current (A) | 200/400 | 200/400 |
| Breading capacity: | ||
| • Active load(A) | 31.5 | 31.5 |
| •No-load transformer(A) | 2.5 | 2.5 |
| •Close loop current(A) | 200/400 | 200/400 |
| •Off-load line(A) | 10 | 10 |
| Rated peak closing capacity(KV) | 12.5 | 12.5 |
| Rated lightning impulse withstand voltage(KV peak) | ||
| •To earth and between poles | 125 | 170 |
| •Across the isolating distance | 145 | 195 |
| Rated 1min power frequency withstand 50 Hz/1 min(KV) | ||
| •To earth and between poles | 50 | 70 |
| •Across the isolating distance | 60 | 80 |
| Rated short-time withstand current(KA 1s) | 5 | 5 |
| Rated peak withstand current(KA) | 12.5 | 12.5 |
| Machanical endurance(cc) | 1000 | 1000 |
Advantage
• No maintenance required.
• Easy pole top mounting.
• Line works can be carried in safe conditions thanks to the visible opening and high level
of insulation.
• A manual control mechanism is available with a rod assembly and padlockable lever.
• Whip breaking system.
• The ISAR-S switch control mechanisms are equipped with a tumbler spring system which
directly operates the mobile shaft.
The operating speed is not dependant on the operator.
• Height of the pole from 9 to 11 m.
• Synthetic Insulators designed with a central part in epoxy resin. The flexible skirts in over
molded silicone provide an important creepage distance and a good protection against
vandalism.
