IP65 Outdoor With Terminal Junction Box SHJK

In daily life and work, whether it is home appliances or industrial control devices, junction boxes are needed for wire connections.

Plastic junction boxes are widely used in the low-voltage electrical field, exhibiting features such as fire resistance, insulation, corrosion resistance, and acid and alkali resistance. The terminals inside the junction box are designed with a fixed structure, making them less prone to loosening and ensuring secure and stable wire connections.

Characteristic:

Colour: RAL 7035

Type of cover: Cover

Number of rows: 1

Product accessories: Mounting fittings

IP protection level: IP65

Flame retardant: 750℃ （30s）

ENVIRONMENTAL CONDITION

Application area: Indoor/Outdoor installation

Maximum ambient temperature 24 h: 35 °C

Ambient temperature: -5 °C up to +40 °C

Relative humidity: ≤ 50 % at 40 °C, ≤ 100 % at 25 °C

ELECTRIC BOX PERFORMANCE

Rated voltage: Un = 400 V

Rated insulation voltage：Ui:690V

Protection class:II

Rated current (of the terminal):In = 75 A

N separable:No

conforming to the standards:EN 60670-1, DIN EN 60670-24

MATERIAL CHARACTERISTICS

Material:PC

According to IEC 60695-2-11 glow wire test temperature:750 °C

UL 94 Class:V-2

Temperature resistance:-25 °C up to +80 °C

Halogen-free:Yes

Silicone-free:Yes

Metallurgy, steel, nuclear power plant, power plant, chemical industry, tunnel engineering, subway, charging pile, photovoltaic

01. Manufacturer Offering Competitive Pricing and High Quality.

We are a direct-sales manufacturer offering both competitive pricing and high-quality products, helping you gain a foothold in the market—specifically in Wenzhou, Zhejiang Province, China. You are warmly invited to visit our company.

02. OEM/ODM Services.

We are a manufacturer backed by an exceptional and highly collaborative team.

03. Standard Payment Terms.

We accept various payment methods, including Telegraphic Transfer (TT) in advance, Letters of Credit (L/C), Western Union, and others. Please feel free to contact us if you have any questions!

04. Warranty Period.

1.5 years. Any quality issues will be resolved through free replacements included with your next order.

05. Free Samples.

Yes, we provide samples of smaller products for your quality assessment; you are only required to cover the courier fees.
