LV-ABC double anchoring deviation 100° and surge arresters

Publish Time: Author: Site Editor Visit: 310

LV-ABC double anchoring deviation 100° and surge arresters

Typical applications:

Line branches, overvoltage protection

Application variants:

Support,support size,number of masts,support material(wood,steel,concrete) cable cross section,construction

Network data:

LV-ABC line: 3x70+54.6mm² Maximum line deviation 50°

Material list:

No. Product name Product code QTY Unit
1 Stainless steel straps 0.7x20 2 meter
2 Stainless steel yoke L20 2 pc
3 Cable tie 9x400 6 pc
4 Anchor Bracket  SM81 1 pc
5 Anchoring clamp(Aluminum alloy) DR1500 1 pc
6 Insulation piering connector SM2-95 5 pc
8 Surge arrester SMSA 5 pc
