Pole mounted fuse switch

LV Fuse Cutouts

Model Number:
APDM630/3P
Standard:
IEC60947
Supply Ability:
30000/month
Color:
Black or customized

LV Fuse Cutouts

SMICO APDM Pole Mounted fuse switch disconnectors are used for protecting low-voltage networks. They combine the functions of a fuse, a switch and a disconnector.

Pole fuse switches are easy to use as they can be operated from the ground by using a rod.They are also reliable and work for decades even in the most severe conditions.

Their reliability and safety has been proved in numerous tests in accordance with IEC and national standards. We manufacture 160 A and 400 A pole fuse switches.

General Description:
APDM630 three pole fuse swith disconnector it is used either as an operation or protection device for LV lines .It is designed to be used with NH 1-2or 3 size fuses offering a maximum of 630 Amps of line protection without blades .
In case blades are used ,the maximum switching load would be 800 Amps .
It is manufactured in reinfored fiberglass polyamide and fulfills all the necessary requirements for outdoor installation and operation .
In the APDM 160C model the connection is made with connectors suitable for aluminum and copper conductors with a section range between 16 and 95 mm2 (5-4/0 AWG) .
The closure of the cap allows the switch to be closed with or without a fuse ,prey enting the risk of leaving tension parts exposed .It may also be provided with a light emission diode(LED) .

Pole fuse switch disconnectors:
APDM Pole fuse switch disconnectors are used for protecting low-voltage networks. They combine the functions of a fuse, a switch and a disconnector.

Pole fuse switches are easy to use as they can be operated from the ground by using a rod.They are also reliable and work for decades even in the most severe conditions.

Their reliability and safety has been proved in numerous tests in accordance with IEC and national standards. We manufacture 160A 400A and 630A pole fuse switches.

Safe, cross-usable and easy to operate. The new APDM family extends with bigger pole fuse switch disconnectors for 400 A 500 V.

Pole fuse switches include separate terminal covers for in-coming and out-going conductors, thus making installation safer.

Products are very durable and long-lasting, guaranteed SMICO quality. They are used for protecting stranded overhead cables and underground cables in low voltage networks. Now all SMICO Pole fuse switch disconnectors have been renewed.

Now the overall range has the same benefits:

  • Safe and easy to install
  • Separate terminal covers
  • Operating stick
  • Suitable for extreme conditions
  • Type tested
  • Laser marking
  • Robust locking mechanism.

Technical Characteristics:


Voltage
500V
Insulation level 1000V
Frequency 50/60Hz
Operational current with fuse 160A
Operational current with blades 250A
Installation category AC22
Short lasting current (1s) 3.2kA
Dynamic current (crest ) 25KA
Interruption capacity 100KA
Minimum mechanical life (operation ) 1000
Weight 600G
Protection range IP23
