You Can Understand The Implementation Process Of The Technical Elements Of The Suspension Wire Clamp!

1.ab cable suspension clamp is used for the installation of optical cables or low-voltage insulated wires. It has a U-shaped bracket and a clamping block made of elastic insulating material fixedly installed in the bracket. The through groove is set on the central axis for clamping the cable. The through groove and the top surface of the clamping block have openings connected to it. The bracket includes one and two clamping arms for clamping the clamping block. The pivot shaft connects the bottom of the two clamping arms. The clamping arms have mounting parts for fixing the bracket. The clamping block can be fixed with one clamping arm. The locking part set at the opening of the bracket can put the two clamping arms together and be used to clamp the clamping block.

2.abc suspension clamp There is a fixing hole at the lower end of one clamping arm, and the side of the clamping block close to the clamping arm has a protruding part that matches the fixing hole. The length of one clamping arm is required to be greater than the length of the second clamping arm.

3.j hook suspension clamp The locking part includes a screw rod, one end of the screw rod has a cam and the other end has a nut, a clamp arm has a locking groove that can be passed through by the screw rod near the upper edge of the clamp block, two clamp arms have two locking grooves arranged opposite to each other, the nut is installed at the two locking grooves, and a through hole connected to the locking groove is arranged above the locking groove; the diameter of the cam is larger than the diameter of the two locking grooves, and the diameter of the cam must be smaller than the diameter of the through hole.

4.suspension clamp for ab cable Folding edges are arranged on the edges of both sides of the clamp arm, and a groove matching the folding edge is arranged on the circumferential surface of the clamp block that contacts the two clamp arms; a convex block and a groove matching the diameter of the screw rod are arranged on the top surface of the clamp block, and when the screw rod locks the two clamp arms, the screw rod will be stuck in the groove.
