What Is The Wiring Schematic Diagram Of A Single-phase Active Energy Meter With Line Fittings Via A Current Transformer?

Insulation Piercing Connector What is the wiring schematic diagram of a single-phase active energy meter through a current transformer?

The wiring diagram of a single-phase active energy meter with a current transformer to measure energy. The wiring method of a single-phase active energy meter with a current transformer to measure the energy of a three-phase four-wire symmetrical load is: When a single-phase active energy meter with only a current transformer is used to measure the energy consumed by a three-phase four-wire symmetrical load, this method directly measures the energy consumed by any phase load.
