The Structure Of Wedge-type Parallel Groove Clamp

groove clamp The material is generally forged aluminum, consisting of an arched body and a wedge. Gun-shaped special tools are used for installation or removal, but they cannot be reused. The slope of the two sides of the wedge is the same as that of the body, which can make the wire evenly stressed in the contacted section and establish self-locking between materials; the arched body provides the elastic force required to maintain stable pressure. The radius of curvature of the inner groove of the arched body and the radius of the outer groove of the wedge are slightly larger than the radius of the maximum applicable wire. During installation, the two straight wires to be connected are placed in the corresponding positions on both sides of the body, and the wedge is pushed to the mark line position by manpower, and then the gun-shaped special tool is fired to generate an instantaneous thrust to press the wedge into the working position. The pressure on the wedge is mainly determined by the amount of medicine in the special bullet, which reduces the influence of human factors on the installation quality, so the consistency of parallel groove installation is better. parallel groove clamp connector Can connect two wires of equal diameter and different diameters. pg clamp connector The wire holding force is approximately 20%-45% of the calculated breaking force of the wire.
