Insulation Accessories

12KV Insulator Electrical Insulation Three-Way Contactor Box SO11-12-150

Brand:
SMICO
Voltage:
12KV
Color:
RED

The contactor box is an electrical connection device widely used in high-voltage circuits. It consists of a main body box, terminals, contacts, etc., which can effectively connect the power supply to the electrical equipment.
The contactor box has a wide range of uses and is widely used in various industries such as lighting, electrical appliances, machinery, communications, and transportation. It is especially suitable for occasions where multiple electrical connections with multiple devices are required.

12KV Insulator Electrical Insulation Three-Way Contactor Box SO11-12-150

1. Rated voltage: 12kV;
2. Rated current: 150A;
3. Withstand short-time (4 seconds) opening current: 12.5kA;
4. Withstand short-time (4 seconds) closing current: 31.5kA;
5. Rated frequency: 50/60Hz;
6. Protection level: IP65;
7. Number of operations: 2000 times;
8. Temperature range: -40℃~+70℃;
9. Weight: about 1.1kg.
