Switchgear Insulation Accessories

12kv High Current High Voltage Epoxy Resin Insulated Contact Box 3-12-190

Brand:
SMICO
Voltage:
12KV
Color:
RED

Description

12kv High Current High Voltage Epoxy Resin Insulated Contact Box 3-12-190

Specification

Rated voltage 12kV
Rated current 190A
Withstand short-time (4 seconds) opening current 16kA
Withstand short-time (4 seconds) closing current 40kA
Rated frequency 50/60Hz
Protection level IP65
Number of operations 2000 times
Temperature range -40℃~+70℃
Weight about 2.7kg

Advantage

The contactor box is an electrical connection device widely used in high-voltage circuits. It consists of a main body box, terminals, contacts, etc., which can effectively connect the power supply to the electrical equipment.
The contactor box has a wide range of uses and is widely used in various industries such as lighting, electrical appliances, machinery, communications, and transportation. It is especially suitable for occasions where multiple electrical connections with multiple devices are required.
