Distribution box

Plastic Wall Mount Electric Distribution Box

The characteristics of the wall-mounted distribution box are waterproof, dustproof, and UV-resistant. SelHot can cut holes according to customer requirements, with complete specifications and easy installation.

...
Model Number:
SHXC

Description:

SMICO's plastic Wall Mount Electric Distribution Box installation is the most common installation method and is usually used for the installation of small distribution boxes. The wall-mounted distribution box has the characteristics of simple installation, small space occupation, and convenient maintenance.

Parameter:

Plastic Wall Mount Electric Distribution Box

Characteristic:

High protection level: IP65 waterproof and dustproof, ensuring stable operation in various environments.

UV-resistant and flame-retardant: PC shell design, effectively resists UV rays and has flame-retardant properties.

Flexible configuration: 4-way module design, can be configured with 1000V DC isolation switch, type 2 DC arrester, etc.

Safe and reliable: finger safe touch design, LITTEL fuse 10A-30A, protects user safety.

Strong environmental adaptability: suitable for indoor/outdoor installation, ambient temperature -5°C to +40°C, humidity conditions meet standards.

High-quality materials: ABS shell/PC door, glow wire test temperature 650°C, UL 94 V-2 flame retardant rating, temperature resistance -25°C to +80°C.

Easy to install and maintain: wall-mounted design with transparent cover for easy observation and maintenance of internal electrical components.

Electrical performance: rated voltage Un=400V, rated insulation voltage Ui: 690V, rated current In=75A.

Comply with international standards: Comply with EN 60670-1, DIN EN 60670-24 and other international standards to ensure product quality and safety.
